1.25G 120KM 1000BASE 1550nm SMF GLC-ZX-SM Optical LC SFP Transceiver DOM(2 pcs)

Description

• Fiber Optic Receivers
• 1.25G 120KM 1000BASE 1550nm SMF GLC-ZX-SM Optical LC SFP Transceiver DOM

Fiber Optic Receivers
1.25G 120KM 1000BASE 1550nm SMF GLC-ZX-SM Optical LC SFP Transceiver
General
120km Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (). They simultaneously comply with Gigabit Ethernet as specified in IEEE STD 802.3 and 1x Fibre Channel as defined in FC-PI-2 Rev. 10.0 .They are compliant and lead-free.
Features
Up to 1.25Gb/s dual data links
-pluggable SFP footprint
1550nm DFBlaser transmitter
APD Receiver
Duplex LC connector
Up to 120km on 9/125m SMF
Metal enclosure for lower EMI
Single +3.3V power supply
<;700mW
Commercialoperating temperature range: 0C to+70C
Applications
Gigabit Ethernet
1.06 Gb/s Fibre Channel
When bidding the product, please leave message for your switch .
1.25G SFP Transceivers
GLC-SX
100BASE-SX SFP 850nm LC 550M
GLC-LX/LH
100BASE-LH SFP 1310nmLC 10KM
GLC-EX-1310
100BASE-EX SFP 1310nm LC 40KM
GLC-EX-1550
100BASE-EX SFP 1510nm LC 40KM
GLC-ZX
100BASE-ZXSFP 1550nm LC 80KM
GLC-ZX-120
100BASE-ZX SFP 1510nm LC 120KM
GLC-ZX-160
100BASE-ZX SFP 1550nm LC 160KM
GLC-ZX-200
100BASE-ZX SFP 1510nm LC 200KM
Product Show
Optical Characteristics (TOP=25C, Vcc=3.3 Volts)O
Parameter
Symbol
Min
Typ
Max
Unit
Ref.
Transmitter
Output Opt. Power
PO
0 - +5
dBm
1
Optical Wavelength
1540
- 1570
nm
Spectral Width
- - 1 nm
Optical Rise/Fall Time
tr/tf
- 170
260
ps
2
Deterministic Jitter Contribution
TXDJ
- - 0.07
UI
3
Total Jitter Contribution
TXTJ
- - 0.007
UI
Optical Extinction Ratio
ER
9 - - dB
Receiver
Average Rx Sensitivity
RSENS
- - -32
dBm
4
Maximum Received Power
RXMAX
-9
- - dBm
Optical Center Wavelength
C
1
